Get The Most From Nikon’s Auto AF Fine Tune System

Do you have a Nikon camera that features Auto AF Fine Tune? If so, then this video is just what you need to get the most from it!

When Auto AF Fine Tune first came it, it was pretty exciting – In fact, I think we all had visions of never going through a tedious lens calibration process ever again. However, the reality is, it didn’t seem to work all that well and many people – myself included – were disappointed.

As it turns out, there IS a way to get good results from the system, it just takes a little more effort than we were lead to believe – and that’s what this tutorial reveals. In the video below, I’ll cover what AF Fine Tuning is, how to do a proper setup (including a handy focus target I made for the purpose that you can download), how to avoid pitfalls, and an Auto AF Fine tuning technique that works as well as using a commercial product.

If you’ve had problems with Auto AF Fine tune before, you’ll discover the method in the video will work far better and give you much better results. Currently, this only applies to the Nikon D850, D7500, D500, and D5, but I’m sure as other cameras are added they will also include this feature (i.e. like the upcoming D850).





AF Target download (zipped PDF file) – Click here

Getting an error message? Here are the most likely culprits:

1. Make sure your Live View AF point is perfectly centered (it should show a small red dot in the middle of the AF area if it is). Also, use the “Normal” or “Wide” AF area in Live View.

2. Make sure your are in AF-S mode, VR is OFF, and the lens is wide open.

3. Make sure you are on a VERY secure tripod – any motion at all during the test can cause failure.

4. Make sure you have a good, well lit target.

5. Make sure you are in single point AF and that you are in the exact center of the viewfinder.

6. Focus on the target using Live View AF and make 100% sure you are perfectly sharp – zoom in. If it’s not sharp, you’ll get an error.


PS…
